F2-WF12D4-156
    SUBWOOFER

SPECIFICATION:

Features:
• Black Anodized Pure Steel Metal Frame for extra strength
• Hybrid Kevlar bonded spruce pulp cone for deep
and accurate sound
• Dual Four-Layered 2.5" Kapton Voice Coils for extra high
power handling
• Gigantic Dual Stacked Magnet structure for extreme power handling
• Ultra wide Rubber santoprene surround foam design for improved sensitivity
• Screw plated lock-binding terminals for maximum
connectivity
• Progressve Spider for optimum performance


Specifications:
• Maximum Power Handling: 1000 Watts
• Continuous Power Handling: 500 Watts
• Frequency Response: 30-300 Hz
• Sensitivity: 86 dB at 1W/1M
• Impedance: 4 Ohms
• Recommended Amplifier Rating: 500 Watts RMS
• Recommended Enclosure: Vented 1.25 Cu.ft.
• Close box 0.75 Cu.ft
• Vented 1.25 Cu.ft. Port 18.5 Sq.in Length 13 inch
