Box Parameters
Vb = 1.32 cu.ft
V(total) = 1.603 cu.ft
Fb = 53.77 Hz
QL = 7
F3 = 41.57 Hz
Fill = none

Vents
No. of Vents = 1
Vent shape = round
Vent ends = one flush
Dv = 5 in
Lv = 10 in

Driver Properties
Description
Type: Standard
One-way driver
Configuration
No. of Drivers = 1

Mechanical
Parameters
Fs = 28.2 Hz
Qms = 7.64
Vas = 37.7 liters
Cms = 0.111 mm/N
Mms = 280g
Rms = 6.65 kg/s
Xmax = 13.75 mm
Xmech = 27.5 mm
P-Dia = 250 mm
Sd = 490 sq.cm
P-Vd = 0.672 liters

Electrical
Parameters
Qes = 0.5
Re = 1 ohm
Z = 2 ohms
BL = 10.1 Tm
Pe = 500 watts

Electromech.
Parameters
Qts = 0.47
no = 0.164%
1-W SPL = 84.1 dB
2.83-V SPL = 93.2 dB
